LSENS-P

LSESNP
LENSP-1

LSENS-P

Capteur de température pour mesurer la plage de température cryogénique jusqu’à 4 °Kelvin. temps de réponse de 0,2 s et avec une zone sensible de la sonde de 0,7 mm de diamètre.

CARACTÉRISTIQUES PRINCIPALES

  • Petite pointe Polyimide, protégée
  • Répétabilité exceptionnelle avec une grande flexibilité
  • Immunité complète aux rayonnements RFI, EMI, RMN et micro-ondes
  • Ne nécessite pas de recalibrage ou d’entrées complexes pour fonctionner
  • Plage de température cryogénique (jusqu’à 4 °Kelvin)

Temperature sensor for measuring cryogenic temperature range as low as 4 °Kelvin. response time of 0.2s and with probe sensitive area of 0.7 mm Diameter.
A multiuse fiber optic temperature sensor designed for a wide range of applications, especially for the use in demanding applications. The standard temperature sensor has a response time of 0.2 s. With a standard deviation of +/-0.2 °C it allows precise and repeatable measurements. The coating of the temperature sensor is made of PTFE, and the fiber tip has 0.3 mm x 0.3 mm area with a Polyimide coating. The fiber optic probe consists of a PTFE protected glass fiber and a GaAs-crystal (Gallium Arsenide) at the sensor tip. The sensor offers complete immunity to RFI, EMI, NMR and microwave radiation.

  • Electric Vehicle and Battery Testing
  • High voltage environments
  • Nuclear and Hazardous environments
  • Medical applications
  • Chemical and Process Industries
  • RF and Microwave drying applications
  • Cryogenic and vacuum environment available (Optional)
  • Sensors do not require any calibration
  • No shift over time, high stability
  • Optional spiral wrap
  • Robust fiber optic temperature sensor
  • Available in different cables and sheath options
  • Customizable according to customer specific applications
  • Suitable for OEM type applications

SPÉCIFICATIONS TECHNIQUES

Temperature range
-200 °C to +250 °C
Temperature range (Optional Range extensions)
Down to 4 °K / Up to +300 °C
Repeatability
0.2 °C
Accuracy absolute temperature
+/- 0.8 °C
Accuracy relative temperature
+/- 0.2 °C
Probe sheathing material
Teflon Coated, with Polyimide protection for sensor tip
Connector
Stainless Alloy / Optional - Dielectric
Response time
Up to 0.2 Sec
Probe sensitive area - Diameter
0.7 mm
Protective Tube - Diameter
Teflon / 1.4 mm
Longevity
Probe accuracy & repeatability constant over time
