LSENS-U

LSENS-U

A Heavy-duty fiber optic temperature sensor for measurement in a wide range of demanding applications where robustness of sensors, immunity to electromagnetic fields and explosion proof requirements are mandatory.

KEY FEATURES

  • Heavy duty protection gives longevity to sensors under harsh and dynamic operating conditions
  • Complete immunity to RFI, EMI, NMR and microwave radiation
  • Outstanding repeatability improves accuracy of testing instruments
  • Plug and Play operation, does not require recalibration or complex input to operate
  • Liquid proof and withstands aggressive chemical solutions

A Heavy–duty fiber optic temperature sensor for measurement in a wide range of demanding applications where robustness of sensors, immunity to electromagnetic fields and explosion proof requirements are mandatory.

A heavy-duty fiber optic temperature sensor specially designed for harsh and dynamic operating conditions where stress on the Fiber Optic Cable is more than normal. The sensor offers complete immunity to RFI, EMI, NMR, Corrosive, and microwave radiation making it the best choice for all demanding applications. The standard temperature sensor has a response time of 0.2 s. with a standard deviation of +/-0.2 °C. Each sensor allows precise and repeatable measurements. The coating of the temperature sensor is made of heavy-duty material, while the fiber tip has a diameter of 1.1mm and has a stainless-steel ST-connector. For mechanical stability and applications e.g., in oil special protective coatings and hoses are available.

  • RF and microwave drying applications
  • Food Processing and sterilization applications
  • Electric Vehicle and Battery Testing
  • Medical Applications
  • Industrial process control and monitoring applications
  • Nuclear, Magnetic and hazardous environments
  • High voltage environments
  • Aggressive Chemical environments
  • Longer life of sensors under harsh and dynamic operating conditions
  • Cost saving on recalibration; sensor does not require any recalibration
  • Customizable to meet different requirements of customer applications
  • Optional spiral wrap reinforces robustness of sensor cable
  • Suitable for OEM-type applications and during operation of machines
  • Higher accuracy and repeatability increase confidence of validation and measurement
  • Faster support from industry known fiber optic experts
  • Available in different cables and sheath options
TECHNICAL SPECIFICATIONS
Temperature range
-200 °C to +250 °C
Measurement range (Optional Range extensions)
Down to 4 °K / Up to +300 °C
Repeatability
0.2 °C
Accuracy absolute temperature
+/- 0.8 °C
Accuracy relative temperature
+/- 0.2 °C
Probe sheathing material
Teflon Coated
Connector
Stainless Alloy / Optional - Dielectric
Response time
Up to 0.2 Sec
Probe sensitive area - Diameter
1.6 mm
