T301

T301

Rugged, Compact and Robust Temperature Monitoring System for Continuous Online Monitoring and Testing.

KEY FEATURES

  • Rugged, Compact Design
  • 4 to 24 Channels, Expandable
  • Plug and Play, No field calibration
  • Best in class EMI, ESD Immunity
  • 8 Programmable relays, Form – C
  • Software designed to be interfaced with
  • Other testing platforms

T301- Rugged, Compact and Robust Temperature Monitoring System for Continuous Online Monitoring and Testing

The Rugged Monitoring T301 is a multi-channel fiber optic temperature monitor with precision measurement for Industrial and Laboratory applications. The T301 Fiber optic monitor combines compact form factor and user-friendly interface in the monitor and software. It is designed to operate reliably in extreme EMI, RFI, Microwave and high voltage environments. The T301 has a measuring range from -80 °C to +300 °C.
The system offers complete immunity to RFI, EMI, Chemical, microwave radiation, and high voltages making it an optimal choice for environments where the limitations of conventional temperature sensors / monitors impact usage in extreme conditions. The system is based on proven zero-drift GaAs technology and designed for Plug and Play operation.

  • Transformer Hot Spot monitoring
  • Industrial process control and monitoring
  • Electric Vehicle and Battery Testing
  • Medical Equipment Testing (MRI, PETSCAN, NMR)
  • Commercial Grade Microwave Radiation
  • Food and Beverage Processes
  • No shift over time, high stability
  • Robust packaging
  • Each Monitor comes with a complete NIST
  • calibration Certificate
  • Software designed for integration into test platforms
  • Robust datalogging and analytics
  • Customizable according to customer specific applications
  • Suitable for OEM-type applications
TECHNICAL SPECIFICATIONS
Measurement Range
-80 °C to +300 °C (cryogenic 4 °K range optional)
Measurement range (Optional Range extensions)
Down to 2 °K / Up to +300 °C
Power Supply
24V to 48V DC, 30 W
Resolution
0.1 °C
Accuracy
±1.0 °C (±0.2 °C in relative temperature)
Scan rate
200 ms / channel
Memory
MicroSD external memory slot (Up to 2 TB)
Logging
10 years at 10 sec interval rate (8 GB)
Serial Port
RS-485 with Modbus
Ethernet Option
RJ-45 or Fiber Ethernet; Optional PRP support built-in 2 x RJ-45 or Fiber Ethernet; With advance communication protocols (IEC 61850, Modbus over Ethernet, IEC 60870-5-104 and DP3)
Fiber Optic Communication
SFP module can be added to the Ethernet option; the standard SFP module is compatible with LC fiber connectors (850 nm multimode communication with a distance capability of 550 meters)
Analog Outputs
8 fully configurable 0-10 V / 4-20 mA optional module available - Optional
Max # of Channels
256 Channels, Daisy chain up to 32 units (with Modbus)
Relays
8 Programmable Form-C Relays (5A) plus 1 system fault relay - Optional
Operating temp
-40 to 72 °C
Storage temp
-40 to 85 °C
Number of Channels
4 - 24 channels
Dimensions
10.5’’ x 7.4” x 2.8’’ 26.7W x 18.7D x 7.2H cm
Humidity
95% Non Condensing
